Zetor Proxima GP Series User Manual

Performance on rear PTO shaft
Lifting force of the three-point hitch
Tensile force
Tractor type GP 80 GP 90 GP 100 GP 110
PTO power (kW ± 2%)
- at rated engine speed and pto rated speed
1,000 min
-1
Engine not run-in 43.5 50 55 62.5
Engine run-in (after 100 EH) 46 52.5 58 65.5
Tractor type GP 80 GP 90 GP 100 GP 110
Lifting power at the end of the lower hinges
of three-point hitch in the entire stroke range
at maximum utilizable pressure with 2 outer
cylinders
- cylinder diameter 75 mm (kN)
39.7
Lifting power at the end of the lower hinges
of three-point hitch in the entire stroke range
at maximum utilizable pressure (kN)
27
Tractor type GP 80 GP 90 GP 100 GP 110
Maximum tensile force (kN) in the swinging
rod on the concrete, tractor in standby with
HS ballast, up to 15% slippage
33.5 35 36.5 38
MAIN TECHNICAL PARAMETERS
211
