Zetor Proxima HS 120 User Manual

Front drive axle fenders
Rear wheels wheel track
Gauges of the tractor rear wheels equipped with screwed footer discs
A
re on adjustable holders which can be set both
horizontally (by relocating screws 'a' to different holes) and
vertically (by relocating screws 'b' to different hole) based
on requested wheel tracks and the kind of used tires.
C508
Used tires Tire width in mm Adjustable tread
12,4-36 315 1350 - 1800
13,6-36 348 1350 - 1800
14,9-28 315 1425 - 1800
14,9R28 378 1425 - 1800
16,9-28 429 1425 - 1800
16,9R28 429 1425 - 1800
16,9-30 429 1425 - 1800
16,9R30 429 1425 - 1800
480/70R30 479 1425 - 1800
18,4 -30 467 1500 - 1800
18,4 R30 468 1500 - 1800
16,9-34 429 1425 - 1800
16,9R34 429 1425 - 1800
480/70R34 429 1425 - 1800
18,4-34 467 1500 - 1800
18,4R34 467 1500 - 1800
WHEEL TREAD CHANGE
146
