Rear window
Side window
Emergency exits
Sun screen
Is equipped with a handle and in an open position is
locked by gas spruts. Rear window is heated.
When driving on an uneven surface we
recommend to secure the window in a closed position
- danger of window cracking. Before starting the work
with the machinery Before starting the work with
mounted in three-point hitch of the tractor, make sure
that there is not a danger of collision between the
mounted tools with maximum lifting of rear three-
oint hitch and open rear window. In case of collision
we recommend to work with a closed window.
C15N025
The window is secured in the partly open position with
a plastic latch. You can open the door by lifting the latch
towards yourself upwards and pushing it into the groove.
Then, the window will be secured in the fixed position.
C123
In case of overturning of the tractor or blocking the exit
from the tractor use the left or the right door, the rear
opening window or the roof opening window as
emergency exits.
P15N085
Pull out the adjustable screen of the front window (1) by
pulling the hand rail in the arrow direction.
To return to the original position, shortly pull the hand rail
in the direction of the arrow and release the hand rail.
The sliding cover of the swing lid (2) is closed and opened
with pressure or by pulling the slots in the arrow direction.
C15N146
ACQUAINTANCE WITH TRACTOR
