Zetor Proxima HS 120 User Manual

Backward travelling speed of the tractor - 40 km/h
Hi - road speeds, Lo - reduced speeds, H - higher multiplier stage, L - lower multiplier stage
Rear independent PTO shaft rotation
Gear
Multiplier
stage
Tractor speed in km/h at the nominal
engine speed (2200 rpm) and defined
dimensions of the rear wheel tyres
Speed of the dependent rear
PTO 540/1000 at the
nominal engine speed (2200
rpm)
Speed of the
dependent rear
PTO 540/540E at
the nominal
engine speed
(2200 rpm)
16.9 - 34 18.4 -34 540 rpm 1000 rpm
540
rpm
540E
rpm
4 Hi
H 38.2 39.5 757 1 430 1 130 1 430
M 33.1 34.2 656 1 239 979 1 239
L 28.6 29.5 567 1 070 846 1 070
3 Hi
H 26.3 27.2 521 984 778 984
M 22.8 23.5 452 853 674 853
L 19.7 20.3 391 737 583 737
2 Hi
H 16.5 17.0 327 618 488 618
M 14.2 14.7 282 531 420 531
L 12.3 12.7 244 460 364 460
1 Hi
H 11.1 11.4 220 415 328 415
M 9.58 9.90 190 359 283 359
L 8.28 8.55 164 310 245 310
4 Lo
H 9.69 10.02 757 1 430 1 130 1 430
M 8.38 8.66 656 1 239 979 1 239
L 7.24 7.48 567 1 070 846 1 070
3 Lo
H 6.67 6.90 521 984 778 984
M 5.77 5.96 452 853 674 853
L 4.98 5.15 391 737 583 737
2 Lo
H 4.17 4.31 327 618 488 618
M 3.61 3.73 282 531 420 531
L 3.12 3.22 244 460 364 460
1 Lo
H 2.81 2.90 220 415 328 415
M 2.43 2.51 190 359 283 359
L 2.1 2.17 164 310 245 310
mark rotation shaft rotation/engine rotation shaft rotation/engine rotation
540/1000
540 540 / 1987 598 / 2200
1000 1000 / 1950 1128 / 2200
540/540E
540 540 / 2005 592 / 2200
540E 540 / 1584 750 / 2200
MAIN TECHNICAL PARAMETERS
199

Zetor Proxima HS 120 Specifications

General

Cylinders	4
Displacement	4.156 L
Hydraulic Pump Flow	60 l/min
Hydraulic System	Open center
PTO Speed	540/1000 RPM
Max Speed	40 km/h
Engine Power	117 HP
Transmission	24F + 24R
PTO Power	104 HP
