Speed of the Zuidberg front PTO
*- optional
E80
Clearance-circle and turning circle diameter
Direction of
rotation
Speed of output shaft / speed of engine Speed of output shaft / speed of engine
right (a) 1,000 / 1,920 1,146 / 2,200
*left (b) 1,000 / 2,000 1,100 / 2,200
Wheel track
front 1,610mm
To the left (mm)
To the right
(mm)
rear 1,500mm
Track diameter
(mm)
Without engaged front driving axle (PHN) 11,850 11,380
Without engaged front driving axle with partial braking
of the inner rear wheel
9,880 9,650
With engaged front driving axle 12,570 12,130
With engaged front driving axle with partial braking of
the inner rear wheel
8,750 8,580
Contour
diameter (mm)
Without engaged front driving axle 12,160 11,720
Without engaged front driving axle with partial braking
of the inner rear wheel
10,190 9,990
With engaged front driving axle 12,880 12,400
With engaged front driving axle with partial braking of
the inner rear wheel
9,060 8,920
MAIN TECHNICAL PARAMETERS
