Technical data of engines
Tractor type Proxima HS 100 Proxima HS 110 Proxima HS 120
Engine type 1017 1317 1417
Engine kind diesel, four-stroke with direct fuel injection, turbocharged
Engine design in-line, vertical, water cooled
Engine revolutions control electronic
Number of cylinders 4
Displacement
cm
3
4156
Bore x stroke mm 105x120
Nominal speed rpm 2200
Injection sequence 1-3-4-2
Compression ratio 17
Max. overspeed rpm 2460
Idle speed rpm 800 ± 25
Net power at the nominal
speed (ECE R24)
kW
66 74 81
Fuel consumption at the
nominal engine speed (2200
rpm) (ECE R24)
g/kWh
238 240 233
Max. torque (1,480 rpm)
(ECE R24)
Nm
408 459 491
Inclination Mt (ECE R24) % 42 43 40
Fuel consumption at the
maximum torque (1,480
rpm) (ECE R24)
g/kWh
220 206 212
Engine lubrication Pressure type with a gear pump
Maximum consumption of oil
after 100 hours of engine
running-in
g/kWh
0,5 0,5 0,5
Oil pressure at the nominal
engine speed and the oil
temperature of 80°C
MPa
0,2 - 0,5 0,2 - 0,5 0,2 - 0,5
Minimum oil pressure at the
engine speed of 750 rpm
and oil temperature of 80°C
MPa
0,08 0,08 0,08
Max. coolant temperature °C 106
Timing type OHV
Timing angle ° 13
Valve clearance with the
engine cold
- suction
- exhaust
mm
mm
0,3
0,3
MAIN TECHNICAL PARAMETERS
192
