Air brakes of trailers and semi-trailers
Warning indication of air pressure drop
One-hose and two-hose brakes
One-hose brakes
Air brakes of trailers (semi-trailers) and brakes of the
tractor are designed so that braking effects of both
vehicles are synchronised.
In case of a drop of pressure the transfer valve
disables the secondary consumers (differential lock,
disengagement of the front driving axle).
When driving with a trailer or semi-trailer the foot
brake pedals shall be coupled and secured by a latch!
With braking by one brake pedal the trailer air brakes
are not activated.
C222
Air pressure drop below 450 kPa is signalized by alit red
control bulb placed on a dashboard.
Tractor with braked trailer or articulated trailer
with pressured drop in air pressure system under 450
kPa must not continue in transport if there is not
increase in air pressure.
C15N092
1. clutch head of one-hose brakes
2. clutch heads of two-hose brakes
Clutch heads after disconnection or without
a connected trailer, articulated trailer must be closed
by a valve.
P11NX227
Valve is marked with a black colour.
Operating pressure is adjusted with the control valve at
600 ± 20 kPa.
When connecting the trailer (articulated trailer)
with a maximum allowed wei
ht approved for the t
pe
of tractor at stake is a maximum allowed speed of the
set of 30 km per hour! Maximum allowed speed of the
set is defined by maximum allowed speed of the
slower vehicle of the set.
P11NX228
