Zetor Proxima HS 120 User Manual

Indication of DPF and SCR errors on the display of the instrument panel
type of
indication
amount of
urea in
the tank
urea signal lamp display -
prompt to
refill urea
defect
signal
lamp
acoustic
signal
reduction of power
and limitation of
engine revolutions
signal
lamp
display
type
1st degree
of warning
less than
20%
orange
signal
lamp
activated
short-time
display
(3 s)
1 x 1 s
2nd degree
of warning
less than
15%
orange
signal
lamp
flashes
(0.5 Hz)
short-time
display
(3 s)
1 x 1 s
3rd degree
of warning
less than
10%
orange
signal
lamp
flashes
(0.5 Hz)
Continuous
display
(The prompt
disappears
after
pressing
any button
on the
instrument
panel.)
2 x 3 s
1st degree
of limitation
less than
5%
orange
signal
lamp
flashes
(1 Hz)
Continuous
display
(The prompt
disappears
after
pressing
any button
on the
instrument
panel.)
2 x 3 s reduction of power
by 25%
2nd degree
of limitation
less than
3%
red signal
lamp
flashes
(2 Hz)
Continuous
display
2 x 3 s reduction of power
by 50%, limitation of
max. engine
revolutions to ca.
1,250 rpm)
Error messages with the signal lamps and acoustic signal
are accompanied by indication on the display of the
instrument panel.
1 - The symbol of the defect significance.
2 - Node of the tractor where the defect appeared.
3 - Main display field - defect code.
4 - Secondary display field - defect specification.
5 - Service symbol.
Note: More information in chapter Instrument Panel
S15N044
SYSTEM OF ADDITIONAL TREATMENT OF EXHAUST GASES
74
