Zetor Proxima HS 120 User Manual

Front tires steerability
Tyre size
Travel speed
40 km.h
-1
30 km.h
-1
Tyre loading capacity (kg) Tyre loading capacity (kg)
tyre
axle inflation (kPa)
tyre
axle inflation (kPa)
1 pc 1 pc
11,2-24 1000 2000 240 1250 2500 240
11,2R24 1215 2430 160 1300 2600 160
12,4-24 1120 2240 230 1400 2800 230
12,4R24 1280 2500 120 1500 3000 150
13,6R24 1290 2500 100 1630 3000 140
380/70R24 1310 2500 100 1530 3000 120
Note : (prepared according to technical parameters of tyres Mitas)
The loading capacity values are applicable for front wheel gauge 1,525 - 1,610 mm and are in compliance
with loading capacity of the axle. Inflation values are minimum values, adapted to the maximum permitted
loading capacity of the axle.
In case of driving on hard surfaces it is suitable to increase pressure by 30 kPa with respect to slipping and
abrasion of the tyres.
Change of the load-bearing capacity of the front tyres (%)
Tyre size
Travel speed
20 km.h
-1
8 km.h
-1
Tyre loading capacity (kg) Tyre loading capacity (kg)
tyre
axle inflation (kPa)
tyre
axle inflation (kPa)
1 pc 1 pc
11,2-24 1500 3000 240 1750 3500 240
11,2R24 1300 2600 160 1560 3120 160
12,4-24 1570 3000 200 1960 3920 230
12,4R24 1500 3000 150 1920 3840 160
13,6R24 1630 3000 140 2120 4000 160
380/70R24 1530 3000 120 2120 4000 160
Travelling speed (km/h) diagonal radial
8 + 40 + 50
20 + 20 + 23
30 0 + 7
0 - 20 0
MAIN TECHNICAL PARAMETERS
194
