8 Spare parts and exploded views
8.2. Spare parts - base
3HAC026660-001 Revision: C242
© Copyright 2006-2008 ABB. All rights reserved.
8.2. Spare parts - base
Base, spare part list
The spare parts for the base are listed below and shown in the following figure.
Item no. Description Spare part no. Dimension
1 Base, spare 3HAC 023552-001
2 Stop pin 3HAB 3258-1
3 Cover base, spare 3HAC 023554-001
4 Gasket, base cover 3HAC 022047-001
6 VK-cover 3HAA 2166-26 D=180, B=12
7 Serial measurement unit 3HAC 023424-001
8 Push button unit 3HAC 020967-001
9 Battery pack 3HAC 16831-1 Lithium
34x102x63
11 Push button guard 3HAC 6499-1
12 Signal cable SMB 3HAC 4050-1
13 Torx pan head screw 9ADA 618-56 Steel 8.8-A2F
M6 x 16
14 Centering piece 3HAC025815-001
100 Cable harness IRB 1600/1.45 3HAC 021827-001
102 Cable harness IRB 1600/1.45, Customer
connections
3HAC 021828-001
106 Cable harness IRB 1600/1.45, Wire
feeder
3HAC 021830-001
108 Cable harness, Motor 1-2 3HAC 023754-001
109 Cable harness IRB 1600/1.2, Customer
connections
3HAC 021828-003
Continues on next page
