8 Spare parts and exploded views
8.4. Spare parts - frame
3HAC026660-001 Revision: C246
© Copyright 2006-2008 ABB. All rights reserved.
8.4. Spare parts - frame
Frame, spare part list
The spare parts are listed below and shown in the following figure.
Item no. Description Spare part no. Dimension
13 Torx pan head screw 9ADA 618-56 Steel 8.8-A2F
M6 x 16
20 Gearbox axis 1-2, spare 3HAC 023555-001
21 Stop arm 3HAC 022001-001
22 Cover, gearbox axis 1-2 3HAC 023556-001
23 Gasket, gearbox axis 1-2 3HAC 022048-001
24 Damper, axis 2 3HAC 022013-001
25 V-ring (sealing ring) 3HAB 3732-21 V-150A
135x12.8
26 Sealing ring (V-ring) 3HAB 3732-13 V-110-L
99x10.5
27 Rot. ac motor incl. pinion, spare 3HAC 023557-001
27 Rot. ac motor incl. pinion,
Cleanroom
3HAC031018-001
28 O-ring 21522012-428 Nitrile rubber
79.5x3
100-109 Cabling See section Base, spare
part list on page 242Base,
spare part list on page
242.
108 Cable harness motor 1 - 2 3HAC 023754-001
