2 Installation and commissioning
2.5.1. Connectors on robot
793HAC026660-001 Revision: C
© Copyright 2006-2008 ABB. All rights reserved.
2.5 Electrical connections
2.5.1. Connectors on robot
Connectors on the robot
The figure below shows all connections of the robot cabling, including the customer
connectors.
xx0400001262
A Connection for air
B Connection for signal lamp
Continues on next page
