3.3.5 Inspecting, cable harness
Location of cable harness, axes 1-6
The axes-1-6 cable harness is shown below.
xx0500002497
Cable harness robot, axes 1-6A
Connectors at baseB
Motor cablesC
Cable guide, axis 2D
Metal clampsE
Continues on next page
Product manual - IRB 660 107
3HAC025755-001 Revision: W
© Copyright 2006-2020 ABB. All rights reserved.
3 Maintenance
3.3.5 Inspecting, cable harness
