2.4 Restricting the working range
2.4.1 Axes with restricted working range
General
When installing the robot, make sure that it can move freely within its entire working
space. If there is a risk that it may collide with other objects, its working space
should be limited.
The working range of the following axes may be restricted:
• Axis 1, hardware (mechanical stop) and software (signal from adjustable
position switch)
As standard configuration, axis 1 is allowed to move ± 180º. The working range
may however be increased to ± 220º with option 561-1 Extended working range
axis 1. Note that this option also requires installation of a position switch on axis
1.
This section describes how to install hardware that restricts the working range.
Note
Adjustments must also be made in the robot configuration software (system
parameters). References to relevant manuals are included in the installation
procedures.
Product manual - IRB 660 77
3HAC025755-001 Revision: W
© Copyright 2006-2020 ABB. All rights reserved.
2 Installation and commissioning
2.4.1 Axes with restricted working range
