3.4.3 Changing oil, gearbox axes 2 and 3
Location of oil plugs
Gearboxes, axes 2 and 3, are located in lower arm rotational center, underneath
motor attachment.
The figure shows the position of gearbox, axis 2.
xx0500002482
Gearbox axis 2A
Oil plug, drainingB
Oil plug, fillingC
Ventilation hole plug, gearbox axis 2D
Continues on next page
