5.7 Checking the synchronization position
Introduction
Check the synchronization position of the robot before beginning any programming
of the robot system. This may be done:
• Using a MoveAbsJ instruction with argument zero on all axes.
• Using the Jogging window on the FlexPendant.
Using a MoveAbsJ instruction
Use this procedure to create a program that runs all the robot axes to their
synchronization position.
NoteAction
On ABB menu tap Program editor.1
Create a new program.2
Use MoveAbsJ in the Motion&Proc menu.3
Create the following program:
MoveAbsJ [[0,0,0,0,0,0],
[9E9,9E9,9E9,9E9,9E9,9E9]]
\NoEOffs, v1000, fine, tool0
4
Run the program in manual mode.5
See Synchronization marks and
synchronization position for axes on
page 309 and Updating revolution
counters on page 311.
Check that the synchronization marks for the axes
align correctly. If they do not, update the revolu-
tion counters.
6
Using the jogging window
Use this procedure to jog the robot to the synchronization position of all axes.
NoteAction
On the ABB menu, tap Jogging.1
Tap Motion mode to select group of axes
to jog.
2
Tap to select the axis to jog, axis 1, 2, or
3.
3
Manually run the robots axes to a position
where the axis position value read on the
FlexPendant, is equal to zero.
4
See Synchronization marks and synchron-
ization position for axes on page 309 and
Updating revolution counters on page 311.
Check that the synchronization marks for
the axes align correctly. If they do not, up-
date the revolution counters.
5
Product manual - IRB 660 331
3HAC025755-001 Revision: W
© Copyright 2006-2020 ABB. All rights reserved.
5 Calibration
5.7 Checking the synchronization position
