3.3.2 Inspecting, oil level gearbox axes 2 - 3
Location of gearbox, axes 2-3
The gearboxes axes 2-3 are located in the lower arm rotational center, underneath
the motor attachment.
xx0500002482
Gearbox, axis 2A
Oil plug, drainingB
Oil plug, fillingC
Ventilation hole, gearbox axis 2D
Continues on next page
98 Product manual - IRB 660
3HAC025755-001 Revision: W
© Copyright 2006-2020 ABB. All rights reserved.
3 Maintenance
3.3.2 Inspecting, oil level gearbox axes 2 - 3
