4 Technical Specifications
4.4 Purge Unit Specifications
36 3HNA009834-001 en Rev.06 Product Manual, Control Cabinet IRC5P
4.4 Purge Unit Specifications
Description The purge unit is used to supply compressed air to the manipulator when the
manipulator is installed in a hazardous area.
A special version of the purge unit, called ‘purge unit w/connector box’ is used for
trolley robots. This purge unit is described in section ’Purge Unit w/Connector Box’
on page 111.
General Specifications
Protection Gas
Air Pressure and
Consumption
Dimensions purge unit: See Figure 16
Dimensions purge unit w/connector box: See Figure 57
Purging sequence time: Depending on robot type. For information, see
manipulator identification label (‘Product Manual,
Manipulator’, System Description).
Dew point: < +2°C at 6 bar
Solid particle size: < 5 microns
Oil content < 1ppm (<1mg/m³)
Min. supply pressure: 3 bar
Air consumption during purging min. 500 NL/min.
Air consumption during maintenance 10-20 NL/min.
Air pressure purging: 3 bar
Air pressure maintenance: 0.5 - 1 bar
