When the function picks up, the PICKUP output is set to TRUE.
• Dimensions are provided both in inches and mm. If it is not specifically
mentioned, the dimension is in mm.
1.4.3 Functions, codes and symbols
All available functions are listed in the table. All of them may not be applicable to a
specific configuration.
Table 1: Functions included in the IED
Function IEC 61850 IEC 60617 REF615R
Protection
Three-phase non-directional overcurrent protection, low stage, instance 1 PHLPTOC1 3I> (1) 51P-1
Three-phase non-directional overcurrent protection, high stage, instance 1 PHHPTOC1 3I>> (1) 50P-1
Three-phase non-directional overcurrent protection, high stage, instance 2 PHHPTOC2 3I>> (2) 50P-2
Three-phase non-directional overcurrent protection, instantaneous stage,
instance 1
PHIPTOC1 3I>>> (1)
50P-3
Three-phase non-directional long time overcurrent protection, low stage,
instance 1
PHLTPTOC1 3I> (3)
51LT
Three-phase directional overcurrent protection, low stage, instance 1 DPHLPDOC1 3I> -> (1) 67/51P
Three-phase directional overcurrent protection, high stage, instance 1 DPHHPDOC1 3I>> -> (1) 67/50P-1
Three-phase directional overcurrent protection, high stage, instance 2 DPHHPDOC2 3I>> -> (2) 67/50P-2
Non-directional earth-fault protection, low stage, instance 1 EFLPTOC1 Io> (1) 51G
Non-directional earth-fault protection, low stage, instance 2 EFLPTOC2 Io> (2) 51N-1
Non-directional earth-fault protection, low stage, instance 4 EFLPTOC4 Io> (4) 50SEF
Non-directional earth-fault protection, high stage, instance 1 EFHPTOC1 Io>> (1) 50G-1
Non-directional earth-fault protection, high stage, instance 2 EFHPTOC2 Io>> (2) 50G-2
Non-directional earth-fault protection, high stage, instance 3 EFHPTOC3 Io>> (3) 50N-1
Non-directional earth-fault protection, high stage, instance 4 EFHPTOC4 Io>> (4) 50N-2
Non-directional earth-fault protection, instantaneous stage, instance 1 EFIPTOC1 Io>>> (1) 50G-3
Non-directional earth-fault protection, instantaneous stage, instance 2 EFIPTOC2 Io>>> (2) 50N-3
Directional earth-fault protection, low stage, instance 1 DEFLPDEF1 Io> -> (1) 67/51N
Directional earth-fault protection, high stage, instance 1 DEFHPDEF1 Io>> -> (1) 67/50N-1
Directional earth-fault protection, high stage, instance 2 DEFHPDEF2 Io>> -> (2) 67/50N-2
Three phase directional power protection, instance 1 DPSRDIR1 I1-> (1) 32P-1
Ground directional power protection, instance 1 DNZSRDIR1 I2 ->, Io-> (1) 32N-1
Negative-sequence overcurrent protection, instance 1 NSPTOC1 I2> (1) 46-1
Negative-sequence overcurrent protection, instance 2 NSPTOC2 I2> (2) 46-2
Phase discontinuity protection PDNSPTOC1 I2/I1> 46PD
Table continues on next page
Section 1 1MRS240044-IB A
Introduction
8 REF615R
Engineering Manual
