5.4 Load Profile tool
Load Profile tool is used for reading load profile records from an IED, clearing old
records and viewing records via an external COMTRADE viewer. The default viewer
included with PCM600 is Wavewin, but a third party viewer can be used.
5.4.1 Opening and closing Load Profile tool
• To open the Load Profile tool, click Load Profile Tool on the context menu of an
IED node inside the PCM600 project tree.
1MRS240044-IB A Section 5
Protection and control engineering
REF615R 75
Engineering Manual
