5.2.5 IED parameter organization
The organization of parameters into a tree structure becomes visible in the Plant
Structure by expanding the setting tree.
5.3 Signal Matrix tool
The Signal Matrix tool is used to make cross-references between the physical I/O
signals and function blocks and for the GOOSE signal input engineering.
The Signal Matrix tool cannot be used for adding or removing function
blocks, for example, GOOSE receive function blocks. The Application
Configuration tool is used for this kind of operations.
Section 5 1MRS240044-IB A
Protection and control engineering
72 REF615R
Engineering Manual
