The Create New Object from Template dialog box is displayed.
5. Delete, import or create a template by clicking the corresponding button.
• To delete the selected template, click Delete Template.
• To import a template from the selection window, click Import Template.
• To insert the selected IED to the bay, click Create.
It is possible to insert more than one IED from the Create New
Object from Template dialog box. The dialog box remains open
until Close is clicked .
6. Click Close when finished.
4.6.4 Inserting an IED by importing a .pcmi file
It is possible to create a new IED object in the plant structure by importing a .pcmi file.
1. In the Plant Structure view, right-click the bay and select Import.
A .pcmi file can be imported only when the bay is selected in the
plant structure.
1MRS240044-IB A Section 4
Setting up a project
REF615R 43
Engineering Manual
