Setting up an IED in the offline mode is similar as in the online mode; however,
with the offline mode it is not necessary to type the correct IP address in the
Communication port and IP address dialog box.
4. On the order code selection page, select the correct order codes.
5. Click Generate to generate the functions for the selected order code.
A Function generation complete dialog box is shown. Click Close.
6. Click Next on the Setup Complete Page that shows the summary of the IED
type, version, IP address and the selected order number.
7. Click Finish to confirm the configuration and conduct the insertion.
4.6.3 Inserting an IED from the template directory
IED templates can be used for replicating IEDs with same order code in PCM600
projects. Template includes IED application configuration, graphical display
configuration (single-line diagram), communication protocol mappings and
parameters. An IED in the plant structure can be exported as a template (.pcmt file).
The template library can be built from all the exported IED templates.
It is also possible to insert an IED from the template library to create a new IED in the
plant structure. After a template IED has been imported, the IP address, the Caption in
IED Object Properties and the Technical Key that corresponds to the physical IED
have to be changed.
A template IED can be inserted only when the bay is selected in the
plant structure.
1. In the Plant structure view, select the bay, right-click, point to New and select
Create from template.
The Create New Object from Template dialog box opens.
1MRS240044-IB A Section 4
Setting up a project
REF615R 41
Engineering Manual
