192.168.2.10 255.255.0.0
Communication fails if the IP addresses of the front and the rear port
belong to the same subnet.
4.4 Creating a new project
1. Start PCM600.
2. To see the projects that are currently available in the PCM databases, select File/
Open/Manage Project on the menu bar.
The Open/Manage Project window is displayed.
3. Click Projects on my computer.
4. Click New Project.
5. If there are currently projects or object tools open, a confirmation dialog box opens.
• Click Yes to close the open projects. A Create New Project dialog box opens.
GUID-F7D1FC0A-CFD5-4A4C-900C-E1F90DEDF3BF V1 EN
Figure 7: New Project dialog box
Section 4 1MRS240044-IB A
Setting up a project
30 REF615R
Engineering Manual
