GUID-F33821B8-2643-4092-85DB-9C732A95C77E V1 EN
Figure 41: Application Configuration tool: validation on demand
5.1.8.3 Validation when writing to the IED
When writing the application configuration to the IED, an automatic validation is
performed. The validation is the same as the manually demanded validation. Errors
abort the writing.
5.2 Parameter Setting tool
Configuration parameters and settings parameters can be changed with LHMI, WHMI
or with the Parameter Setting tool in PCM600.
Some parameters are only visible in the Parameter Setting tool and
some only in LHMI.
A common writing from PCM600 to the IED, where parameters are
changed in the Parameter Setting tool, overwrites any parameter
changes made locally with LHMI.
All variables listed and displayed in the parameter list can be sorted into two groups.
Section 5 1MRS240044-IB A
Protection and control engineering
70 REF615R
Engineering Manual
