• Configuration parameters
• Setting parameters
5.2.1 Configuration parameter
Configuration parameter specifies the operation mode of an application function or of
the IED. These are basic configurations that are normally configured only once and
then not modified again. The IED configures itself during startup according to the
given configuration parameter values.
5.2.2 Setting parameter
Setting parameter (short form: “setting”) is a parameter that can be changed in the IED
at runtime.
5.2.3 Setting group
Nearly all settings used by the IED for protection application functions are organized
into a group of settings. Up to six setting groups can be configured with different values.
The IED supports the selection of a setting group at runtime.
5.2.4 IED parameter import and export
IED parameters can be imported and exported in XRIO file format. The parameter import/
export functionality is available via the File menu when the Parameter Setting tool is
open.
GUID-4A63FE0D-7846-4387-A5D3-BD7B4F519A76 V1 EN
Figure 42: Parameter import/export
1MRS240044-IB A Section 5
Protection and control engineering
REF615R 71
Engineering Manual
