6.2.2 Controlling via the control menu
The primary equipment can be controlled via the LHMI with the Open and Close
buttons when the protection relay is set to the local-control mode and accessing the
control operations is authorized.
1.
Press
to open or to close the object.
•
If there are several controllable objects, select the object with and
and press to confirm the selection.
GUID-B44E0D8C-22B9-4BA4-8BE7-2C4EE9AA85F7 V1 EN
Figure 75: Selecting a controlled object
2.
To confirm the operation, select Yes and press .
GUID-7B64F532-D632-41FA-9F20-ADBEECF0A558 V1 EN
Figure 76: Opening a disconnector
•
To cancel the operation, select No and press .
Section 6 1MRS758754 B
Operating procedures
96 REC615 and RER615
Operation Manual
