Figure 25: Single-line diagram with one switch and ANSI symbols
Select the single-line diagram for the default view in Main menu/
Configuration/HMI/Default view.
When single-line diagram is selected as the default view, the first
single-line diagram page is shown when the default view is entered.
The single-line diagram page can be changed using the left and right
push buttons.
4.1.12.1 Changing single-line diagram symbol formats
1.
Select Main menu/Configuration/HMI/SLD symbol format and press .
2.
Change symbol format with or .
3.
Press
to confirm the selection.
GUID-02F6C094-9B0E-4624-AAD2-780355A3F64B V1 EN
Figure 26: Selecting IEC as single-line diagram symbol format
1MRS758754 B Section 4
Using the HMI
REC615 and RER615 51
Operation Manual
