When editing string values, the cursor moves to the first character.
2.
Press
or to change the value of an active character.
One press changes the value by one step.
3.
Press or to move the cursor to another character.
•
To insert characters or space, press simultaneously and .
•
To delete characters, press simultaneously and .
4.1.14.3 Editing enumerated values
1. Activate the setting mode and select a setting.
When editing an enumerated value, the selected value is shown inverted.
2.
Press
or to change the value of an active enumerated value.
One press changes the enumerated value by one step in the parameter specific
order.
4.1.15 Committing settings
Editable values are stored either in RAM or in non-volatile flash memory. Values
stored in flash memory are in effect also after reboot.
Some parameters have an edit-copy. If editing is cancelled, the values with an edit-
copy are immediately restored to the original value. The values without an edit-copy,
such as string values, are restored to the original value only after a reboot even though
the edited value is not stored in the flash memory.
1.
Press
to confirm any changes.
2.
Press to move upwards in the menu tree or to enter the Main Menu.
3.
To save the changes in non-volatile memory, select Yes and press .
A070891 V3 EN
Figure 32: Confirming settings
1MRS758754 B Section 4
Using the HMI
REC615 and RER615 55
Operation Manual
