GUID-E71F2F31-FF34-40EE-9DD0-19F35EA8E49E V1 EN
Figure 43: Warning indicating that the entered value is incorrect
• If writing values fails, a warning dialog box is displayed.
GUID-D4623C27-645E-4FAA-B288-887FFF99D7B6 V1 EN
Figure 44: Warning indicating that the values were not written to the
protection relay
If writing is enabled accidentally, click Disable Write. Disable
Write cannot be selected when a value has already been written to the
protection relay. After clicking Write to IED, click either Commit or
Reject.
4.2.8 Committing settings
Editable values are stored either in RAM or a nonvolatile flash memory. Values stored
in the flash memory are in effect also after a reboot.
Some parameters have an edit-copy. If editing is cancelled, the values with an edit-
copy are immediately restored to the original value. The values without an edit-copy,
Section 4 1MRS758754 B
Using the HMI
66 REC615 and RER615
Operation Manual
