ABB RER615 User Manual

1.4.2 Document conventions
A particular convention may not be used in this manual.
• Abbreviations and acronyms are spelled out in the glossary. The glossary also
contains definitions of important terms.
• The example figures illustrate the IEC display variant.
• Menu paths are presented in bold.
Select Main menu/Settings.
• WHMI menu names are presented in bold.
Click Information in the WHMI menu structure.
• LHMI messages are shown in Courier font.
To save the changes in nonvolatile memory, select Yes and press
.
• Parameter names are shown in italics.
The function can be enabled and disabled with the Operation setting.
• Parameter values are indicated with quotation marks.
The corresponding parameter values are "On" and "Off".
• Input/output messages and monitored data names are shown in Courier font.
When the function starts, the START output is set to TRUE.
1.4.3 Functions, codes and symbols
All available functions are listed in the table. All of them may not be applicable to all
products.
Table 1: Functions included in the relays
Function
IEC 61850 IEC 60617 IEC-ANSI
Protection
Three-phase non-directional
overcurrent protection, low stage,
instance 1
PHLPTOC1
3I> (1) 51P-1 (1)
FPHLPTOC1 F3I> (1) F51P-1 (1)
Three-phase non-directional
overcurrent protection, high stage,
instance 1
PHHPTOC1
3I>> (1) 51P-2 (1)
Three-phase non-directional
overcurrent protection, instantaneous
stage, instance 1
PHIPTOC1
3I>>> (1) 50P/51P (1)
Three-phase non-directional
overcurrent protection, instantaneous
stage, instance 2
PHIPTOC2
3I>>> (2) 50P/51P (2)
Three-phase directional overcurrent
protection, low stage, instance 1
DPHLPDOC1 3I> -> (1) 67-1 (1)
FDPHLPDOC1 F3I> -> (1) F67-1 (1)
Three-phase directional overcurrent
protection, low stage, instance 2
DPHLPDOC2 3I> -> (2) 67-1 (2)
FDPHLPDOC2 F3I> -> (2) F67-1 (2)
Three-phase directional overcurrent
protection, low stage, instance 3
DPHLPDOC3 3I> -> (3) 67-1 (3)
Table continues on next page
Section 1 1MRS758754 B
Introduction
10 REC615 and RER615
Operation Manual
