Overcur rent
Di r. ea r th- f ault
Combined P rotection
In sync f o close
Frequen c y p ro tection
Brea ker failu re
Di sturb. rec. t rigge red
CB condi t ion moni toring
Supe r vis ion
Aut oreclose shot in p rog.
REA DY
START
PIC K UP TRIP
ESC
CLEAR
R
L
HELP
MENU
CLOSE
OPEN
F1
F4
F3
F2
RE_615
A070704 V5 EN
Figure 2: Example of the LHMI
3.2.1 Display
The LHMI includes a graphical display that supports two character sizes. The
character size depends on the selected language. The amount of characters and rows
fitting the view depends on the character size.
Table 4: Small display
Character size
1)
Rows in the view Characters per row
Small, mono-spaced (6 × 12 pixels) 5 20
Large, variable width (13 × 14 pixels) 3 8 or more
1) Depending on the selected language
Section 3 1MRS758754 B
REC615 and RER615 overview
20 REC615 and RER615
Operation Manual
