Allen-Bradley PowerFlex 20-750-S1 User Manual

194 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 4 Power Wiring
Input Power Circuit Breakers
and Disconnect Switches
Refer to page 17 for an explanation of where to locate drive ratings on the
nameplate.
Table 15 - 400V, 50 Hz Input - Code P3 Thermal Magnetic Circuit Breaker Options
Table 16 - 400V, 50 Hz Input - Code P5 Molded Case Disconnect Switch Options (Floor Mount Frame
8 Only)
kW Amps Duty Line Side Terminal
Lugs
Terminal Size Recommended Torque
200 385 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
250 460 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
456 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
472 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
315 540 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
540 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
540 Heavy 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
315 585 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
567 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
585 Heavy 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
355 612 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
650 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
642 Heavy 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
400 750 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
750 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
770 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
450 796 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
832 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
kW Amps Duty Line Side Terminal
Lugs
Terminal Size Recommended Torque
200 385 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
250 460 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
456 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
472 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
315 540 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
540 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
540 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
315 585 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
567 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
585 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
355 612 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
650 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
642 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
400 750 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
750 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
770 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
450 796 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
832 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
