Rockwell Automation Publication 750-IN001O-EN-P - October 2014 9
Preface
Commonly Used Tools
Installation and Service Tools
This list covers the tools that are needed for drive installation.
Care must be taken to be sure that tools and/or hardware components do not
fall into open drive assemblies. Do not energize the drive unless all loose tools
and/or hardware components have been removed from the drive assemblies
and enclosure.
Tool Description Details
ESD-protected place of work Work surface, Floor cover, seat, and ground connections
ESD-protective clothing Wrist wrap, shoes, overall clothing (coat)
Multimeter Digital multimeter, capable of AC and DC voltage, continuity, resistance,
capacitance measurements, and forward diode bias tests. Fluke model 87 III or
equivalent.
Allen socket wrench 4 mm, 5 mm
Allen-socket wrench extension 254 mm (10 in.)
Flat-nose screw driver 5 mm (0.19 in.), 6.4 mm (0.25 in.), 9.5 mm (0.375 in.), #1, #2
Hexalobular screw driver/bit #15, #20, #25, #40, #45
Hexagonal socket wrench 7 mm, 8 mm, 10 mm, 12 mm, 13 mm, 17 mm, 18 mm
Combination wrench 10 mm, 17 mm
Phillips® screw driver/bit
(1)
(1) Phillips and Pozidriv are registered trademarks of the Phillips Screw Company.
#2, 492-C
Pozidriv®
(1)
#2, M3 x 7
Torque wrench 1...12 N•m (8.8…106 lb•in)
Torque wrench 6...50 N•m (53…443 lb•in)
Roll-out cart 20-750-CART1-F8
Note: The roll-out cart is required to remove the Frame 8 and larger drive
assembly from the enclosure.
