Rockwell Automation Publication 750-IN001O-EN-P - October 2014 35
Chapter 3
Lift and Mount the Drive
Drive Weights
All lifting equipment and lifting components (hooks, bolts, lifts, slings, chains,
and so forth) must be properly sized and rated to safely lift and hold the weight of
the drive while mounting.
Table 3 - Approximate Drive Weights - Wall Mount Frames 1…7 and Floor Mount Frames 8…10
ATTENTION: To guard against possible personal injury and/or equipment
damage…
• Inspect all lifting hardware for proper attachment before lifting drive.
• Do not allow any part of the drive or lifting mechanism to make contact with
electrically charged conductors or components.
• Do not subject the drive to high rates of acceleration or deceleration while
transporting to the mounting location or when lifting.
• Do not allow personnel or their limbs directly underneath the drive when it is
being lifted and mounted.
Drive Frame
Size
Drive Rating Enclosure Code/Weight kg (lb)
kW (400V, 690V) Hp (480V, 600V) FGNR
Standard
(20F, 20G)
AC Input
and Common
DC Input
1 0.75…7.5 1…10
6 (13)
2 0.75…11 1…15 8 (17) 8 (17) 8 (17)
3 15…22 0.5…30 12 (26) 12 (26) 12 (26)
4 30…37 20…50 14 (30) 14 (30) 14 (30)
5 45…55 30…70 20 (45) 20 (45) 20 (45)
6 5.5…75 75…100 37 (82) 89 (197) 37 (82)
45…132 50…200 38 (84) 91 (200) 39 (85)
7 132…200 150…300 69 (152) 135 (297) 79 (174)
200…250 300…350 96 (212) 162 (357) 106 (234)
B, L P, W J K, Y
Standard
(20G)
AC Input 8 250…400 350…650 623 (1374) 1145 (2525) 644 (1419) 1166 (2570)
9 500…850 700…1250 1246 (2748) 2290 (5051) 1287 (2838) 2332 (5141)
10 900…1250 1350…1750 1869 (4122) 3435 (7576) 1931 (4257) 3498 (7711)
Common DC
Input
8 250…400 350…650 566 (1248) 1088 (2400) 586 (1293) 1109 (2445)
9 500…850 700…1250 1132 (2497) 2176 (4799) 1173 (2587) 2218 (4889)
10 900…1250 1350…1750 1698 (3745) 3264 (7199) 1760 (3880) 3327 (7334)
with
Options
(21G)
AC Input 8 250…400 350…650 1145 (2525) 1675 (3694) 1166 (2570) 1696 (3739)
9 500…850 700…1250 1730 (3815) 2820 (6219) 1771 (3905) 2862 (6309)
10 900…1250 1350…1750 2315 (5106) 3965 (8745) 2377 (5241) 4028 (8880)
