Diagmessages of module TorqueControl

Multi axis servo system - AX8000190

Version: 1.1

12.6 6389, Parameter Torque Control: The value in object is

higher then the configured peak current

The rated current is higher then the channel peak current.

Diagnostic Code (Hex.) Diagnostic Code (Dez.)

6389 25481

Class Type

Error Error

Standard Reaction Reset

Axis is inoperable Execute Reset-Command (Fault reset).

Possible Causes Solutions

Something is wrong with the parameters in this

object.

Please check the parameters of the mentioned

object.

Internal: 0x6389, Parameter Torque Control: The value in object 0x%x/%x is higher then the configured peak

current (0x%x/%x).

Default Chapter3
