Diagmessages of module SyncServoMotor

Multi axis servo system - AX8000214

Version: 1.1

16.2 6387, Parameter Motor. The configured DCLink Max

Voltage is higher then the Motor Max Voltage.

The configured DCLink Max Voltage is higher then the Motor Max Voltage.

Diagnostic Code (Hex.) Diagnostic Code (Dez.)

6387 25479

Class Type

Error Error

Standard Reaction Reset

Closed loop ramp Execute Reset-Command (Fault reset).

Possible Causes Solutions

Something is wrong with the parameters in this

object.

Please check the parameters of the mentioned

object.

Internal: 0x6387, Parameter Motor. The configured DCLink Max Voltage is higher then the Motor Max

Voltage.

Default Chapter3
