USER mode
In the USER mode, DTC and
ENGINE can be set individually.
- ENGINE: It is possible to
choose between RAIN, ROAD
and DYNAMIC
- DTC: It is possible to choose
between RAIN, ROAD and DY-
NAMIC
The changed USER settings are
saved until the next change.
Changing setting
The riding modes can only be
changed while driving under the
following condition:
No drive torque at rear wheel
No brake pressure in the brake
system
This operating mode is active
when the motorcycle is stopped
with the ignition switched ON. As
an alternative, the following steps
must be carried out:
Turn back throttle grip
Do not actuate brake lever
First the desired riding mode is
preselected. The new selection
is not activated until the specified
conditions are present in all af-
fected systems.
Tire Pressure Control
with Tire Pressure Control
(TPC)
OE
Operation
A sensor located in each tire
monitors the air temperature and
the inflation pressure inside the
tire and transmits this information
to the control unit.
The sensors are equipped with a
centrifugal governor, which does
not enable the transmission of
the measured readings until the
defined minimum speed is ex-
ceeded for the first time.
Minimum speed for
transmission of TPC
measured data:
min 19 mph (min 30 km/h)
Before initial reception of the tire
inflation pressure, -- is shown
in the display for each tire. The
sensors continue to transmit the
measured readings for some af-
ter the vehicle comes to a stop.
Duration of measured
data transmission after
motorcycle is stationary:
min 15 min
If an TPC control unit is fitted but
the wheels have no sensors, a
fault message is generated.
7
105
z Technology in detail

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
