BMW R 1200R 2015 User Manual

Threaded fasteners
Front wheel Value Valid
Brake caliper on telescopic
forks
M10 x 65 28 lb/ft (38 Nm)
Quick-release axle in telescopic
fork
M20 x 1.5 37 lb/ft (50 Nm)
Clamping screw for quick-re-
lease axle in telescopic fork
M8 x 35 Tighten the screws 6 times, alternating
between one and the other each time
14 lb/ft (19 Nm)
Rear wheel Value Valid
Tighten rear wheel on wheel
flange
M10 x 1.25 x 40 Tighten diagonally
44 lb/ft (60 Nm)
11
163
z Technical data

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
