BMW R 1200R 2015 User Manual

To exit individualization menu
at any point in time, press and
hold button 1.
All adjustments applied until
then will be stored.
Anti-Theft Alarm
System
with anti-theft alarm system
(DWA)
OE
Information on alarm
activation
The alarm can be set off by:
Motion sensor
An attempt to use an unau-
thorized key to switch on the
ignition
Disconnecting the DWA from
the motorcycle battery (DWA
battery takes over the power
supply – alarm sound only, haz-
ard warning lights do not flash).
If the DWA battery is discharged
all functions remain operational;
the only difference is that the
alarm cannot be set off if the
system is disconnected from the
motorcycle battery.
Duration of alarm
26 s (During the alarm, an
alarm tone sounds and the
turn indicators flash. The type
of alarm sound can be set by
an authorized BMW Motorrad
retailer.)
If an alarm was triggered while
the motorcycle was unattended,
the rider is notified accordingly
by an alarm tone sounding once
when the ignition is switched on.
The DWA indicator light then sig-
nals the reason for the alarm for
one minute.
The meanings of the flash codes
are as follows:
1 flash: motion sensor 1
2 flashes: motion sensor 2
3 flashes: ignition switched on
with unauthorized key
4 flashes: DWA disconnected
from motorcycle battery
5 flashes: motion sensor 3
DWA Adjusting
Switching on ignition ( 46).
Repeatedly press button 1
briefly, until ENTER is shown
in top line of display 2.
4
62
z Operation

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
