BMW R 1200R 2015 User Manual

Secure hold
If a case wobbles or is difficult to
fit, it must be adapted to the gap
between the upper and lower
mount.
Incorrectly fastened cases
can reduce driving safety.
Cases may not shake and must
be fastened play-free. If some
play is determined after longer
use, the retaining claw must be
readjusted.
Use the screws 1 inside the case
for this purpose.
Topcase
with Topcase
OA
Opening topcase
Turn key in Topcase lock into
Position 1.
Press lock barrel 1 forward.
Release lever 2 pops up.
9
149
z Accessories

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
