Resetting tripmeter
Switching on ignition ( 46).
Repeat pressing button 1
briefly, until tripmeter to be
reset is shown in top line of
display 2.
Press and hold button 1, main-
taining pressure until displayed
figure resets.
Reset average data
Switching on ignition ( 46).
Repeat pressing button 1
briefly, until average value to be
reset is shown in bottom line of
display 2.
Press and hold button 1, main-
taining pressure until the dis-
played figure resets.
Configure onboard
computer
The motorcycle is stopped.
Switching on ignition ( 46).
Repeatedly press button 1
briefly, until SETUP EN-
TER is shown in top line of
display 2.
Press and hold button 1 to
start SETUP menu.
The following is indicated in
the display depending on the
equipment selected.
4
57
z Operation

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
