BMW R 1200R 2015 User Manual

Rear brake fluid level
Brake fluid, DOT4
The brake fluid level must
not fall below the MIN mark.
(Brake-fluid reservoir horizon-
tal, motorcycle standing up-
right)
If brake fluid level falls below the
approved level:
Have defect corrected as soon
as possible by an authorized
workshop, preferably an autho-
rized BMW Motorrad retailer.
Clutch
Check clutch function
Pull back the clutch lever.
Pressure point must be clearly
perceptible.
If no clear pressure point can be
felt:
Have the clutch checked by an
authorized workshop, preferably
an authorized BMW Motorrad
retailer.
Coolant
Checking coolant level
Fold out side stand and posi-
tion yourself on right-hand side
of motorcycle.
Hold motorcycle straight.
with center stand
OE
Place motorcycle on center
stand, ensuring that it is rest-
ing on a firm and level support
surface.
Danger of burns on hot en-
gine.
Maintain distance from hot en-
gine.
Do not touch hot engine.
Read off coolant level on ex-
pansion tank 1.
Coolant level must be between
MIN and MAX marks.
If coolant level drops below MIN
mark:
Add coolant.
Topping up coolant
Checking coolant level
(
118).
8
118
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
