Engage the brakes repeatedly,
continuing until the brake pads
seat against the rotors.
Locate wheel speed sensor
lead in the retaining clips 1
and 2.
Insert wheel speed sensor in
bore and install screw 3.
Wheel speed sensor on
fork
Joint compound: Micro-
encapsulated or medium-
strength screw lock
6 lb/ft (8 Nm)
Removing rear wheel
Swivel muffler ( 127).
Shift into first gear.
Remove bolts 1 of rear wheel,
holding wheel as you do so.
Roll rear wheel out toward rear.
Installing rear wheel
Malfunctions may occur
during control interventions
by ABS or ASC/DTC if a wheel
other than the standard wheel is
installed.
Please see the information on
the effect of wheel sizes on the
ABS and ASC/DTC chassis con-
trol systems at the beginning of
this chapter.
Threaded fasteners not
tightened to the specified
torque can work loose or their
threads can suffer damage.
Always have the tightening
torques checked by a specialized
workshop, preferably an
authorized BMW Motorrad
retailer.
Place rear wheel on rear wheel
support.
Install wheel studs 1 with spec-
ified torque.
8
126
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
