BMW R 1200R 2015 User Manual

with Pure windshield
OE
Place windshield 2 in position.
Install screws 1.
Windshield in bracket
3 lb/ft (4 Nm)
Replacing parking light
light source
Park motorcycle, ensuring that
support surface is firm and
level.
Switch off ignition.
with Pure windshield
OE
Remove screws 1. When do-
ing so, make sure not to lose
the shouldered bushings in the
grommets.
Remove windshield 2.
Remove screws 2 and take off
cover 1.
Loosen screw 1 2 rotations.
8
132
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
