BMW R 1200R 2015 User Manual

To be able to apply force more
easily, insert the interchange-
able screwdriver bit 1, Torx end
first, into the screwdriver han-
dle 2 (from motorcycle toolkit).
Locate specified tool from ve-
hicle toolkit on oil fill location 3
and turn counterclockwise.
Check engine oil level ( 112).
Both too little and too
much engine oil can lead to
engine damage.
Always make sure that the oil
level is correct.
Add engine oil up to specified
level.
Engine oil, quantity for
topping up
max 1 quarts (max 0.95 l) (Dif-
ference between MIN and
MAX)
Check engine oil level ( 112).
Install the oil filler cover 3.
Brake system
Checking brake operation
Actuate the handbrake lever.
Pressure point must be clearly
perceptible.
Actuate the footbrake lever.
Pressure point must be clearly
perceptible.
If no clear pressure points are
perceptible:
Incorrect working practices
endanger the reliability of
the brake system.
Have all work on the brake sys-
tem carried out by experts.
Have the brakes checked at an
authorized workshop, preferably
an authorized BMW Motorrad
retailer.
Check front brake pad
thickness
Park motorcycle, ensuring that
support surface is firm and
level.
Visually inspect left and right
brake pads to determine their
thickness. Viewing direction:
between wheel and front
suspension toward brake
pads 1.
8
114
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
