BMW R 1200R 2015 User Manual

Headlight range
adjustment
When the spring pretension ad-
justment is no longer able to
maintain the correct beam height
to avoid blinding oncoming traffic
owing to high vehicle loads:
Loosen screws 1 with onboard
toolkit.
Do not place motorcycle
on center stand or side
stand.
Swing headlight downward
somewhat (depending on pay-
load) to lower headlight light.
If the motorcycle is ridden again
with lower payload:
Have the headlight default set-
ting readjusted by an autho-
rized workshop, preferably an
authorized BMW Motorrad re-
tailer.
Tighten screws 1 with onboard
toolkit.
Clutch
Adjusting clutch lever
Adjusting the clutch lever
while driving can lead to
accidents.
Only adjust the clutch lever when
the motorcycle is stationary.
Turn adjusting wheel 1 into
desired position.
The adjustment wheel can
be turned more easily if you
press the clutch lever forward
when doing so.
Four settings are available:
Position 1: smallest distance
between handlebar grip and
clutch lever
Position 4: largest distance
between handlebar grip and
clutch lever
5
77
z Setting

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
