BMW R 1200R 2015 User Manual

Rear wheel
Rear wheel design Aluminum cast wheel
Rear-wheel rim size 5.5" x 17"
Rear tire designation 180/55 - ZR 17
Load index for rear tire At least 67
Permissible rear-wheel imbalance max 1.6 oz (max 45 g)
Tire inflation pressures
Tire pressure, front 36.3 psi (2.5 bar), with tire cold
Tire pressure, rear 42.1 psi (2.9 bar), with tire cold
Electrical system
Electrical rating of onboard sockets max 5 A, all onboard sockets together
Fuse carrier 1 10 A, Slot 1: instrument cluster, anti-theft alarm
system (DWA), ignition lock, main relay and diag-
nostic socket
7.5 A, Slot 2: left multifunction switch, Tire Pres-
sure Control (TCP), yaw rate sensor
Fuse carrier 50 A, Fuse 1: alternator regulator
11
171
z Technical data

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
