BMW R 1200R 2015 User Manual

Resuming former cruising
speed
Briefly push button 1 back to
return to the speed saved be-
forehand.
Opening the throttle does
not deactivate the cruise-
control system. If you release the
throttle grip, the motorcycle will
decelerate only to the cruising
speed saved in memory, even
though you might have intended
slowing to a lower speed.
Cruise-control system indi-
cator light lights up.
Switch off cruise-control
system
Push switch 1 to left.
The system is deactivated.
Button 2 is locked.
Heated handlebar grips
with heated handlebar grips
OE
Operating heated grips
The heated grips option
can only be activated when
the engine is running.
The increase in power con-
sumption caused by the
heated grips can drain the bat-
tery if you are riding at low en-
gine speeds. If the battery is in-
adequately charged, the heated
grips are switched off to ensure
starting capability.
Start engine ( 86).
Press button 1 repeatedly un-
til desired heating level 2 is
shown.
The handlebar grips can be
heated at two different levels.
4
72
z Operation

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
