BMW R 1200R 2015 User Manual

Brakes
Type of front brake Hydraulically operated twin disk brake with 4-pis-
ton radial calipers and floating brake disks
Brake-pad material, front Sintered metal
Type of rear brake Hydraulic disk brake with 2-piston floating caliper
and fixed brake rotor
Brake-pad material, rear Organic
Wheels and tires
Recommended tire combinations An overview of the current tire approvals is avail-
able from your authorized BMW Motorrad retailer
or on the Internet at bmw-motorrad.com.
Speed category of front/rear tires W, minimum requirement: 168 mph (270 km/h)
Front wheel
Front wheel design Aluminum cast wheel
Front-wheel rim size 3.5" x 17"
Front tire designation 120/70 - ZR 17
Load index for front tire At least 49
Permissible front-wheel imbalance max 0.2 oz (max 5 g)
11
170
z Technical data

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
